基于Android-Skin-Loader实现换肤效果

skin-loader框架的换肤是通过插件化的形式替换资源文件，实现换肤效果。好处是可以在线更新皮肤换肤

Demo样例

流程

整个框架大概的流程是加载皮肤包，找到被标记的控件，通过自定义的Factory工程过滤掉其他控件，使用皮肤包中的资源文件更新被标记的ui。

使用操作

1、导入android-skin-loader框架包
androidStudio File->new->import Module选择android-skin-loader
项目右键->open Module Setting->app中加载依赖android-skin-loader库

2、在MyApplication 初始化框架

SkinManager.getInstance().init(this);
SkinManager.getInstance().load();

3、需要换肤的activity需要继承skin-loader中的BaseActivity
需要换肤的控件添加skin:enable=”true”，控件xml添加命名空间xmlns:skin=”http://schemas.android.com/android/skin”

4、准备需要替换的color或drawable同名的资源文件包将其打包，重命名以.skin结尾
本地测试可以使用adb命令将.skin包放在sdcard
adb push 文件目录/test.skin /sdcard

样例代码

xml文件，使用databinding，不知道的自行百度

<?xml version=\"1.0\" encoding=\"utf-8\"?>
<layout xmlns:android=\"http://schemas.android.com/apk/res/android\"
 xmlns:skin=\"http://schemas.android.com/android/skin\">
 <LinearLayout
  android:layout_width=\"match_parent\"
  android:layout_height=\"match_parent\"
  android:orientation=\"vertical\">
  <LinearLayout
   android:layout_width=\"match_parent\"
   android:layout_height=\"wrap_content\"
   android:orientation=\"horizontal\">
   <Button
    android:id=\"@+id/btn_default\"
    android:layout_width=\"wrap_content\"
    android:layout_height=\"wrap_content\"
    android:textColor=\"@color/text_color\"
    android:background=\"@color/button_background\"
    skin:enable=\"true\"
    android:text=\"默认皮肤\"/>
   <Button
    android:id=\"@+id/btn_change_skin\"
    android:layout_width=\"wrap_content\"
    android:layout_height=\"wrap_content\"
    android:layout_marginLeft=\"20dp\"
    android:textColor=\"@color/text_color\"
    android:background=\"@color/button_background\"
    skin:enable=\"true\"
    android:text=\"更改皮肤\"/>
   <Button
    android:id=\"@+id/btn_add\"
    android:layout_width=\"wrap_content\"
    android:layout_height=\"wrap_content\"
    android:layout_marginLeft=\"20dp\"
    android:textColor=\"@color/text_color\"
    android:background=\"@color/button_background\"
    skin:enable=\"true\"
    android:text=\"动态添加布局\"/>
  </LinearLayout>
  <TextView
   android:layout_width=\"match_parent\"
   android:layout_height=\"wrap_content\"
   android:textColor=\"@color/text_color\"
   android:text=\"文字文字文字文字文字文字\"
   skin:enable=\"true\" />
  <ImageView
   android:layout_width=\"wrap_content\"
   android:layout_height=\"wrap_content\"
   android:src=\"@drawable/skin\"
   skin:enable=\"true\"/>
  <LinearLayout
   android:id=\"@+id/add_layout\"
   android:layout_width=\"match_parent\"
   android:layout_height=\"wrap_content\"
   skin:enable=\"true\"
   android:orientation=\"vertical\">
  </LinearLayout>

 </LinearLayout>
</layout>

public class SkinChangeAct extends BaseActivity{
 private ActivitySkinchangeBinding binding;
 //skin包名
 private String SKIN_NAME = \"test.skin\";
 //skin皮肤包的路径
 private String SKIN_DIR = Environment.getExternalStorageDirectory()+ File.separator+SKIN_NAME;
 @Override
 public void onCreate(@Nullable Bundle savedInstanceState) {
  super.onCreate(savedInstanceState);
  binding = DataBindingUtil.setContentView(this, R.layout.activity_skinchange);
  //更换皮肤
  binding.btnChangeSkin.setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View view) {
    File skin = new File(SKIN_DIR);
    if(skin == null || !skin.exists()){
     Toast.makeText(getApplicationContext(), \"请检查\" + SKIN_DIR + \"是否存在\", Toast.LENGTH_SHORT).show();
     return;
    }

    SkinManager.getInstance().load(skin.getAbsolutePath(), new ILoaderListener() {
     @Override
     public void onStart() {
      System.out.println(\"start\");
     }

     @Override
     public void onSuccess() {
      System.out.println(\"onSuccess\");
     }

     @Override
     public void onFailed() {
      System.out.println(\"onFailed\");
     }
    });
   }
  });
  //恢复默认皮肤
  binding.btnDefault.setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View view) {
    SkinManager.getInstance().restoreDefaultTheme();
   }
  });
  //动态加载控件
  binding.btnAdd.setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View view) {
    dynamicAddTextView();
   }
  });
 }
 /**动态添加textview*/
 private void dynamicAddTextView() {
  TextView     textView = new TextView(this);
  RelativeLayout.LayoutParams params = new RelativeLayout.LayoutParams(ViewGroup.LayoutParams.WRAP_CONTENT, ViewGroup.LayoutParams.WRAP_CONTENT);
  params.addRule(RelativeLayout.CENTER_IN_PARENT);
  textView.setLayoutParams(params);
  textView.setTextColor(SkinManager.getInstance().getColor(R.color.text_color));
  textView.setText(\"hellohello\");
  textView.setTextSize(28);
  //将动态添加的布局也更换皮肤，否则之前添加的不能更改
  List<DynamicAttr> mDanamicAttr = new ArrayList<DynamicAttr>();
  mDanamicAttr.add(new DynamicAttr(AttrFactory.TEXT_COLOR,R.color.text_color));
  dynamicAddView(textView,mDanamicAttr);
  binding.addLayout.addView(textView);
 }
}

资源文件color.xml

<?xml version=\"1.0\" encoding=\"utf-8\"?>
<resources>
 <color name=\"colorPrimary\">#3F51B5</color>
 <color name=\"colorPrimaryDark\">#303F9F</color>
 <color name=\"colorAccent\">#FF4081</color>
 <color name=\"text_color\">#ff0000</color>
 <color name=\"button_background\">#00ff00</color>
</resources>

skin皮肤包中的资源文件color.xml

<?xml version=\"1.0\" encoding=\"utf-8\"?>
<resources>
 <color name=\"colorPrimary\">#3F51B5</color>
 <color name=\"colorPrimaryDark\">#303F9F</color>
 <color name=\"colorAccent\">#FF4081</color>
 <color name=\"text_color\">#ffff00</color>
 <color name=\"button_background\">#00ffff</color>
</resources>

对比一下，只是更改了数值，名字相同。

框架迭代，增加功能

android-skin-loader框架是没有对于src属性的修改，案例中使用imageView模拟了src的更改。
在AttrFactory中增加对于src的支持

public class AttrFactory {

 public static final String BACKGROUND = \"background\";
 public static final String TEXT_COLOR = \"textColor\";
 public static final String LIST_SELECTOR = \"listSelector\";
 public static final String DIVIDER = \"divider\";
 //增加src属性
 public static final String SRC=\"src\";

 public static SkinAttr get(String attrName, int attrValueRefId, String attrValueRefName, String typeName){

  SkinAttr mSkinAttr = null;
  System.out.println(\"attrName=\"+attrName);
  if(BACKGROUND.equals(attrName)){
   mSkinAttr = new BackgroundAttr();
  }else if(TEXT_COLOR.equals(attrName)){
   mSkinAttr = new TextColorAttr();
  }else if(LIST_SELECTOR.equals(attrName)){
   mSkinAttr = new ListSelectorAttr();
  }else if(DIVIDER.equals(attrName)){
   mSkinAttr = new DividerAttr();
  }else if(SRC.equals(attrName)){
   //自定义加载src
   mSkinAttr =new SrcAttr();
  }else{
   return null;
  }

  mSkinAttr.attrName = attrName;
  mSkinAttr.attrValueRefId = attrValueRefId;
  mSkinAttr.attrValueRefName = attrValueRefName;
  mSkinAttr.attrValueTypeName = typeName;
  return mSkinAttr;
 }

 /**
  * Check whether the attribute is supported
  * @param attrName
  * @return true : supported <br>
  *   false: not supported
  */
 public static boolean isSupportedAttr(String attrName){
  if(BACKGROUND.equals(attrName)){
   return true;
  }
  if(TEXT_COLOR.equals(attrName)){
   return true;
  }
  if(LIST_SELECTOR.equals(attrName)){
   return true;
  }
  if(DIVIDER.equals(attrName)){
   return true;
  }
  //支持src
  if(SRC.equals(attrName)){
   return true;
  }
  return false;
 }
}

srcAttr继承SkinAttr定义加载src

public class SrcAttr extends SkinAttr{
 @Override
 public void apply(View view) {
  if(view instanceof ImageView){
   ImageView imageView = (ImageView) view;
   if(RES_TYPE_NAME_COLOR.equals(attrValueTypeName)){
    imageView.setImageResource(SkinManager.getInstance().getColor(attrValueRefId));
   }else if(RES_TYPE_NAME_DRAWABLE.equals(attrValueTypeName)){
    Drawable bg = SkinManager.getInstance().getDrawable(attrValueRefId);
    imageView.setImageDrawable(bg);
   }
  }
 }
}

各种控件的支持都可以自己添加。
