def figure(num=None, # autoincrement if None, else integer from 1-N
figsize=None, # defaults to rc figure.figsize
dpi=None, # defaults to rc figure.dpi
facecolor=None, # defaults to rc figure.facecolor
edgecolor=None, # defaults to rc figure.edgecolor
frameon=True,
FigureClass=Figure,
clear=False,
**kwargs
):
可以设置图片大小、分辨率、颜色等。
2. subplot子图绘制，子图的绘图参数可以分别设置
plt.figure(1)
x1 = np.linspace(-0.2, 2, 10)
y1 = x1**2 + 0.3
plt.subplot(121)
plt.scatter(x1, y1)
plt.xlabel(\'X\')
plt.ylabel(\'Y\')
plt.title(\'test_1\')
x2 = np.linspace(-0.2, 2, 10)
y2 = x2 + 0.3
plt.subplot(122)
plt.plot(x2, y2, color=\"red\", linewidth=1.0, marker = \'s\', linestyle=\"--\")
## plt.plot(x, y, color=\"#ef5492\", linewidth=2.0, marker = \'s\', linestyle=\"--\")
# plt.plot(x2, y2, \'rs--\')
plt.xlabel(\'X\')
plt.ylabel(\'Y\')
plt.title(\'test_2\')
plt.show()
3. 在同一张图片上显示多种图形，简单说把 plt.show()放在最后即可
import matplotlib.pyplot as plt
import numpy as np
plt.figure(2)
x1 = np.linspace(-0.2, 2, 10)
y1 = x1**2 + 0.3
plt.scatter(x1, y1)
x2 = np.linspace(-0.2, 2, 10)
y2 = x2 + 0.3
plt.plot(x2, y2, color=\"red\", linewidth=1.0, marker = \'s\', linestyle=\"--\")
## plt.plot(x, y, color=\"#ef5492\", linewidth=2.0, marker = \'s\', linestyle=\"--\")
# plt.plot(x2, y2, \'rs--\')
plt.xlabel(\'X\')
plt.ylabel(\'Y\')
plt.title(\'test_3\')
plt.show()
