Python matplotlib读取excel数据并用for循环画多个子图subplot操作

读取excel数据需要用到xlrd模块，在命令行运行下面命令进行安装

pip install xlrd

表格内容大致如下，有若干sheet，每个sheet记录了同一所学校的所有学生成绩，分为语文、数学、英语、综合、总分

考号	姓名	班级	学校	语文	数学	英语	综合	总分
…	…	…	…	136	136	100	57	429
…	…	…	…	128	106	70	54	358
…	…	…	…	110.5	62	92	44	308.5

画多张子图需要用到subplot函数

subplot(nrows, ncols, index, **kwargs)

想要在一张画布上按如下格式画多张子图

语文 — 数学

英语 — 综合

—– 总分 —-

需要用的subplot参数分别为

subplot(321) — subplot(322)

subplot(323) — subplot(324)

subplot(313)

#!/usr/bin/env python
# -*- coding:utf-8 -*-
from xlrd import open_workbook as owb
import matplotlib.pyplot as plt
#import matplotlib.colors as colors
#from matplotlib.ticker import MultipleLocator, FormatStrFormatter, FuncFormatter
import numpy as np

districts=[] # 存储各校名称--对应于excel表格的sheet名
data_index = 0
new_colors = [\'#1f77b4\', \'#ff7f0e\', \'#2ca02c\', \'#d62728\',
    \'#9467bd\', \'#8c564b\', \'#e377c2\', \'#7f7f7f\',
    \'#bcbd22\', \'#17becf\']
wb = owb(\'raw_data.xlsx\') # 数据文件
active_districts = [\'二小\',\'一小\',\'四小\'] ## 填写需要画哪些学校的，名字需要与表格内一致
avg_yuwen = []
avg_shuxue = []
avg_yingyu = []
avg_zonghe = []
avg_total = []
\'按页数依次读取表格数据作为Y轴参数\'
for s in wb.sheets():
 #以下两行用于控制是否全部绘图，还是只绘选择的区
 #if s.name not in active_districts:
  # continue
 print(\'Sheet: \', s.name)
 districts.append(s.name)
 avg_score = 0
 yuwen = 0
 shuxue = 0
 yingyu = 0
 zonghe = 0
 zongfen = 0
 total_student = 0
 for row in range(1,s.nrows):
  total_student += 1
  #读取各科成绩并计算平均分
  yuwen = yuwen + (s.cell(row, 4).value - yuwen)/total_student # 语文
  shuxue = shuxue + (s.cell(row, 5).value - shuxue) / total_student # 数学
  yingyu = yingyu + (s.cell(row, 6).value - yingyu) / total_student # 英语
  zonghe = zonghe + (s.cell(row, 7).value - zonghe) / total_student # 综合
  zongfen = zongfen + (s.cell(row, 8).value - zongfen) / total_student # 总分
 avg_yuwen.append(yuwen)
 avg_shuxue.append(shuxue)
 avg_yingyu.append(yingyu)
 avg_zonghe.append(zonghe)
 avg_total.append(zongfen)
 data_index += 1

print(\'开始画图...\')
plt.rcParams[\'font.sans-serif\']=[\'SimHei\'] # 中文支持
plt.rcParams[\'axes.unicode_minus\']=False # 中文支持
figsize = 11,14
fig = plt.figure(figsize=figsize)
fig.suptitle(\'各校各科成绩平均分统计\',fontsize=18)
my_x=np.arange(len(districts))
width=0.5

ax1 = plt.subplot(321)
#total_width=width*(len(districts))
b = ax1.bar(my_x , avg_yuwen, width, tick_label=districts, align=\'center\', color=new_colors)
for i in range(0,len(avg_yuwen)):
 ax1.text(my_x[i], avg_yuwen[i], \'%.2f\' % (avg_yuwen[i]), ha=\'center\', va=\'bottom\',fontsize=10)
ax1.set_title(u\'语文\')
ax1.set_ylabel(u\"平均分\")
ax1.set_ylim(60, 130)

ax2 = plt.subplot(322)
ax2.bar(my_x, avg_shuxue, width, tick_label=districts, align=\'center\', color=new_colors)
for i in range(0, len(avg_shuxue)):
 ax2.text(my_x[i], avg_shuxue[i], \'%.2f\' %(avg_shuxue[i]), ha=\'center\', va=\'bottom\', fontsize=10)
ax2.set_title(u\'数学\')
ax2.set_ylabel(u\'平均分\')
ax2.set_ylim(50,120)

ax3 = plt.subplot(323)
b = ax3.bar(my_x , avg_yingyu, width, tick_label=districts, align=\'center\', color=new_colors)
for i in range(0,len(avg_yingyu)):
 ax3.text(my_x[i], avg_yingyu[i], \'%.2f\' % (avg_yingyu[i]), ha=\'center\', va=\'bottom\',fontsize=10)
ax3.set_title(u\'英语\')
ax3.set_ylabel(u\"平均分\")
ax3.set_ylim(30, 100)

ax4 = plt.subplot(324)
b = ax4.bar(my_x , avg_zonghe, width, tick_label=districts, align=\'center\', color=new_colors)
for i in range(0,len(avg_zonghe)):
 ax4.text(my_x[i], avg_zonghe[i], \'%.2f\' % (avg_zonghe[i]), ha=\'center\', va=\'bottom\',fontsize=10)
ax4.set_title(u\'综合\')
ax4.set_ylabel(u\"平均分\")
ax4.set_ylim(0, 60)

ax5 = plt.subplot(313)
total_width=width*(len(districts))
b = ax5.bar(my_x , avg_total, width, tick_label=districts, align=\'center\', color=new_colors)
for i in range(0,len(avg_total)):
 ax5.text(my_x[i], avg_total[i], \'%.2f\' % (avg_total[i]), ha=\'center\', va=\'bottom\',fontsize=10)
ax5.set_title(u\'总分\')
ax5.set_ylabel(u\"平均分\")
ax5.set_ylim(250, 400)

plt.savefig(\'avg.png\')
plt.show()

这样虽然能画出来，但是需要手动写每个subplot的代码，代码重复量太大，能不能用for循环的方式呢？

继续尝试，

先整理出for循环需要的不同参数

avg_scores = [] # 存储各科成绩，2维list
subjects = [\'语文\',\'数学\',\'英语\',\'综合\',\'总分\'] #每个子图的title
plot_pos = [321,322,323,324,313] # 每个子图的位置
y_lims = [(60,130), (50,120), (30,100), (0,60), (200,400)] # 每个子图的ylim参数

数据读取的修改比较简单，但是到画图时，如果还用 ax = plt.subplots(plot_pos[pos])方法的话，会报错

Traceback (most recent call last):
 File \"...xxx.py\", line 66, in <module>
 b = ax.bar(my_x , y_data, width, tick_label=districts, align=\'center\', color=new_colors) # 画柱状图
AttributeError: \'tuple\' object has no attribute \'bar\'

搜索一番，没找到合适的答案，想到可以换fig.add_subplot(plot_pos[pos]) 试一试，结果成功了，整体代码如下

#!/usr/bin/env python
# -*- coding:utf-8 -*-
from xlrd import open_workbook as owb
import matplotlib.pyplot as plt
#import matplotlib.colors as colors
#from matplotlib.ticker import MultipleLocator, FormatStrFormatter, FuncFormatter
import numpy as np

districts=[] # 存储各校名称--对应于excel表格的sheet名
total_stu=[] # 存储各区学生总数
data_index = 0
new_colors = [\'#1f77b4\', \'#ff7f0e\', \'#2ca02c\', \'#d62728\',
    \'#9467bd\', \'#8c564b\', \'#e377c2\', \'#7f7f7f\',
    \'#bcbd22\', \'#17becf\']
wb = owb(\'raw_data.xlsx\') # 数据文件
active_districts = [\'BY\',\'二小\',\'一小\',\'WR\',\'四小\'] ## 填写需要画哪些学校的，名字需要与表格内一致
avg_scores = [] # 存储各科成绩，2维list
subjects = [\'语文\',\'数学\',\'英语\',\'综合\',\'总分\'] #每个子图的title
plot_pos = [321,322,323,324,313] # 每个子图的位置
y_lims = [(60,130), (50,120), (30,100), (0,60), (200,400)] # 每个子图的ylim参数

\'按页数依次读取表格数据作为Y轴参数\'
for s in wb.sheets():
 #以下两行用于控制是否全部绘图，还是只绘选择的区
 #if s.name not in active_districts:
  # continue
 print(\'Sheet: \', s.name)
 districts.append(s.name)
 avg_scores.append([])
 yuwen = 0
 shuxue = 0
 yingyu = 0
 zonghe = 0
 zongfen = 0
 total_student = 0
 for row in range(1,s.nrows):
  total_student += 1
  #tmp = s.cell(row,4).value
  yuwen = yuwen + (s.cell(row, 4).value - yuwen)/total_student # 语文
  shuxue = shuxue + (s.cell(row, 5).value - shuxue) / total_student # 数学
  yingyu = yingyu + (s.cell(row, 6).value - yingyu) / total_student # 英语
  zonghe = zonghe + (s.cell(row, 7).value - zonghe) / total_student # 综合
  zongfen = zongfen + (s.cell(row, 8).value - zongfen) / total_student # 总分
 avg_scores[data_index].append(yuwen)
 avg_scores[data_index].append(shuxue)
 avg_scores[data_index].append(yingyu)
 avg_scores[data_index].append(zonghe)
 avg_scores[data_index].append(zongfen)
 data_index += 1

print(\'开始画图...\')
plt.rcParams[\'font.sans-serif\']=[\'SimHei\']
plt.rcParams[\'axes.unicode_minus\']=False
figsize = 11,14
fig = plt.figure(figsize=figsize)
fig.suptitle(\'各校各科成绩平均分统计\',fontsize=18)
my_x=np.arange(len(districts))
width=0.5

print(avg_scores)
for pos in np.arange(len(plot_pos)):
 #ax = plt.subplots(plot_pos[pos])
 ax = fig.add_subplot(plot_pos[pos]) # 如果用ax = plt.subplots会报错\'tuple\' object has no attribute \'bar\'
 y_data = [x[pos] for x in avg_scores] # 按列取数据
 print(y_data)
 b = ax.bar(my_x , y_data, width, tick_label=districts, align=\'center\', color=new_colors) # 画柱状图
 for i in np.arange(len(y_data)):
  ax.text(my_x[i], y_data[i], \'%.2f\' % (y_data[i]), ha=\'center\', va=\'bottom\',fontsize=10) # 添加文字
 ax.set_title(subjects[pos])
 ax.set_ylabel(u\"平均分\")
 ax.set_ylim(y_lims[pos])

plt.savefig(\'jh_avg_auto.png\')
plt.show()

和之前的结果一样，能找到唯一一处细微差别嘛
