python opencv通过按键采集图片源码

\'\'\'

“N”  新建文件夹 data/  用来存储图像
\"S\"   开始采集图像，将采集到的图像放到 data/ 路径下
“Q”   退出窗口
\'\'\'

import numpy as np  # 数据处理的库 Numpy
import cv2          # 图像处理的库 OpenCv
import os           # 读写文件
import shutil       # 读写文件
from PIL import Image, ImageDraw, ImageFont


# # OpenCv 调用摄像头 / Use camera
cap = cv2.VideoCapture(0)
cap.set(cv2.CAP_PROP_FRAME_WIDTH,1920)
cap.set(cv2.CAP_PROP_FRAME_HEIGHT,1080)

\'\'\'
#功能函数，只是用来往图片中显示汉字
#示例 img = cv2ImgAddText(cv2.imread(\'img1.jpg\'), \"大家好，我是片天边的云彩\", 10, 65, (0, 0, 139), 20)
参数说明：
img：OpenCV图片格式的图片
text：要写入的汉字
left：字符坐标x值
top：字符坐标y值
textColor：字体颜色
：textSize：字体大小
\'\'\'
def cv2ImgAddText(img, text, left, top, textColor=(0, 255, 0), textSize=20):
    if (isinstance(img, np.ndarray)):  # 判断是否OpenCV图片类型
        img = Image.fromarray(cv2.cvtColor(img, cv2.COLOR_BGR2RGB))
    # 创建一个可以在给定图像上绘图的对象
    draw = ImageDraw.Draw(img)
    # 字体的格式
    fontStyle = ImageFont.truetype(
        \"font/simsun.ttc\", textSize, encoding=\"utf-8\")
    # 绘制文本
    draw.text((left, top), text, textColor, font=fontStyle)
    # 转换回OpenCV格式
    return cv2.cvtColor(np.asarray(img), cv2.COLOR_RGB2BGR)

# 存储图像的文件夹
current_dir = \"\"
# 保存  图像 的路径
path_photos_from_camera = \"data/\"

press_n_flag = 0
cnt_ss=0



while cap.isOpened():
    flag, img_rd = cap.read()
    #print(img_rd.shape)

    kk = cv2.waitKey(2)
    # 待会要写的字体 / Font to write
    font = cv2.FONT_ITALIC

    # 4. 按下 \'n\' 新建存储人脸的文件夹 / press \'n\' to create the folders for saving faces
    if kk == ord(\'N\') or kk == ord(\'n\'):
        current_dir = path_photos_from_camera
        #os.makedirs(current_dir)
        if os.path.isdir(current_dir):
            pass
        else:
            os.mkdir(current_dir)
        print(\'\\n\')
        print(\"新建的保存图像的文件夹 / Create folders: \", current_dir)

        press_n_flag = 1        # 已经按下 \'n\' / have pressed \'n\'


    # 5. 按下 \'s\' 保存摄像头中的图像到本地 / Press \'s\' to save image into local images
    if kk == ord(\'S\') or kk == ord(\'s\'):
        # 检查有没有先按\'n\'新建文件夹 / check if you have pressed \'n\'
        if press_n_flag:
            cnt_ss += 1
            cv2.imwrite(current_dir + \"/img_\" + str(cnt_ss) + \".jpg\", img_rd)
            print(\"写入本地 / Save into：\", str(current_dir) + \"/img_face_\" + str(cnt_ss) + \".jpg\")
        else:
            print(\"请在按 \'S\' 之前先按 \'N\' 来建文件夹 / Please press \'N\' before \'S\'\")


    # 添加说明 / Add some statements
    #cv2.putText(img_rd, \"Face Register\", (20, 40), font, 1, (0, 255, 0), 1, cv2.LINE_AA)
    img_rd = cv2ImgAddText(img_rd, \"图片采集系统\", 160, 25, (0, 255,0), 30)
    #cv2.putText(img_rd, \"N: Create face folder\", (20, 350), font, 0.8, (0, 255, 0), 1, cv2.LINE_AA)
    img_rd = cv2ImgAddText(img_rd, \"N: 创建保存图像文件夹\", 20, 350, (0, 255, 0), 20)
    #cv2.putText(img_rd, \"S: Save current face\", (20, 400), font, 0.8, (0, 255, 0), 1, cv2.LINE_AA)
    img_rd = cv2ImgAddText(img_rd, \"S: 保存当前图片\", 20, 400, (0, 255, 0), 20)
    #cv2.putText(img_rd, \"Q: Quit\", (20, 450), font, 0.8, (0, 0, 0), 1, cv2.LINE_AA)
    img_rd = cv2ImgAddText(img_rd, \"Q: 退出\", 20, 450, (0, 255, 0), 20)

    # 6. 按下 \'Q\' 键退出 / Press \'q\' to exit
    if kk == ord(\'Q\') or kk == ord(\'q\'):
        break
    # 如果需要摄像头窗口大小可调 / Uncomment this line if you want the camera window is resizeable
    cv2.namedWindow(\"camera\", 0)
    cv2.imshow(\"camera\", img_rd)

# 释放摄像头 / Release camera and destroy all windows
cap.release()
cv2.destroyAllWindows()

pip install pillow

sudo apt-get install python3-pillow

/*****************************************************
2021.5.18:按键采集图像
******************************************************/
#include \"opencv2/core/core.hpp\"
#include \"opencv2/imgproc/imgproc.hpp\"
#include \"opencv2/calib3d/calib3d.hpp\"
#include \"opencv2/highgui/highgui.hpp\"
#include <iostream>
#include <fstream>

using namespace cv;
using namespace std;

#define SRC_WIDTH  1920
#define SRC_HEIGHT 1080

int main()
{
	//测试视频
	VideoCapture capture;
	capture.open(1);
	//capture.open(\"v4l2src device=/dev/video4 ! video/x-raw,width=1920,height=1020,framerate=30/1 ! videoconvert ! appsink\");
	if (!capture.isOpened())
	{
		printf(\"文件打开失败\");
	}
	capture.set(CAP_PROP_FRAME_WIDTH, SRC_WIDTH);        //设置宽度
	capture.set(CAP_PROP_FRAME_HEIGHT, SRC_HEIGHT);  //设置长度
	Mat frame;
	int n = 0;
	char* cstr = new char[120];
	while (true)
	{

		capture >> frame;
		if (frame.data == NULL)
		{
			printf(\"Image is empty\\n\");
			//writer.write(frame);
			break;
			//continue;
		}
		char kk=waitKey(2);
		if (kk == \'S\' || kk == \'s\')
		{

			sprintf(cstr, \"%s%d%s\", \"caliberation/\", n++, \".jpg\");
			imwrite(cstr, frame);
			printf(\"保存了图片\\n\");

		}


		namedWindow(\"111\", 0);//参数为零，则可以自由拖动
		imshow(\"111\", frame);
		waitKey(2);
	}

	return 0;

}
